DRAINAGE

PERCUTANEOUS TRANSHEPATIC GALLBLADDER DRAINAGE

Introduction

Last updated: apr 5, 2023

Laparoscopic cholecystectomy is currently the gold standard for treating acute cholecystitis. In high-risk patients, such as the elderly, critically ill, or those with severe comorbidities, cholecystectomy-related morbidity and mortality markedly increased. Poor surgical candidates may benefit from gallbladder drainage with concomitant antibiotic treatment.

Acute cholecystitis accounts for 14–30% of cholecystectomies and is defined as an inflammation of the gallbladder, usually caused by cystic duct obstruction . The most common causes of cystic duct obstruction are gallstones and cholestasis. Other less common causes include masses (primary tumors or gallbladder polyps), parasites, or foreign bodies.

Grade III (severe) acute cholecystitis
Associated with dysfunction of any one of the following organs/systems:
1. Cardiovascular dysfunction: hypotension requiring treatment with dopamine ≥5 μg/kg per min, or any dose of norepinephrine
2. Neurological dysfunction: decreased level of consciousness
3. Respiratory dysfunction: PaO2/FiO2 ratio <300
4. Renal dysfunction: oliguria, creatinine >2.0 mg/dl
5. Hepatic dysfunction: PT-INR >1.5
6. Hematological dysfunction: platelet count <100,000/mm3

Grade II (moderate) acute cholecystitis
Associated with any one of the following conditions:
1. Elevated WBC count (>18,000/mm3)
2. Palpable tender mass in the right upper abdominal quadrant
3. Duration of complaints >72 ha
4. Marked local inflammation (gangrenous cholecystitis, pericholecystic abscess, hepatic abscess, biliary peritonitis, emphysematous cholecystitis)

Grade I (mild) acute cholecystitis
Does not meet the criteria of “Grade III” or “Grade II” acute cholecystitis. It can also be defined as acute cholecystitis in a healthy patient with no organ dysfunction and mild inflammatory changes in the gallbladder, making cholecystectomy a safe and low-risk operative procedure



Indications

  • Poor surgical candidates
    • When surgery never planned endoscopic ultrasound guided cholecystenterostomy can be performed 1
  • Endoscopic transpapilary gallbladder drainage not feasible 2
  • Grade II and III

  • Drainage should be performed < 24 h. 4



Contra indications

Absolute

  • Impossibility to follow a transhepatic route
    • Consider direct gallbladder access

Relative

  • Coagulation abnormalities
  • Contrast allergy
  • Ascites (paracenthesis first)



Workup

  • Local signs of inflammation
    • Murphy's sign
    • RUQ mass/pain/tenderness
  • Systemic signs of inflammation
    • Fever
    • Elevated CRP
    • Evated WBC count
  • Imaging findings characteristic of acute cholecystitis
    • US
    • CECT (in case of gangrenous, emphysematous)
3



Pre procedural

  • Antibiotics 12-24 h prior
  • Consider sedation Midazolam/Fentanyl



Materials

Essentials

  • Ultrasound
  • Sterile drapes
  • 1% lidocaine
  • Chiba needle
  • 5 ml contrast
  • Amplatz wire
  • 8.5F drain
  • Fixation
  • Drainage bag connector

Non-Essentials



Positioning the patient

  • Supine



The procedure in steps

  • Time out
  • Position the patient
  • Ultrasound to determine the point of entry
  • Sterile wash and drapes
  • Ultrasound guided transhepatic puncture of the gallbladder
  • Inject contrast into the gallbladder
  • Introduction of the wire (Amplatz)
  • Over-the-wire placement of a 7-8 F drain
  • External fixation
  • Sign out



Tips and tricks

  • Make sure to insert the drain as much as possible into the gallbladder, respiration will cause dislocation



Complications

  • Catheter dislodgement 5-15%
  • Minor bleeding 0-1%
  • Sepsis < 1%
  • Death < 1%
  • Pneumothorax rare
  • Abscess rare
  • Bowel injury rare
  • Bile leakage rare
4



Post-op

  • Bed rest for around 4 h
  • Vitals should be recorded every half hourly for first 2 h post procedure.



Report
