Introduction

Last updated: apr 5, 2023

Different causes of portal hypertension

Prehepatic (portal vein obstruction)

  • Congenital atresia or stenosis
  • Thrombosis of portal vein
  • Thrombosis of splenic vein
  • Extrinsic compression (for example, tumours)

Hepatic
  • Cirrhosis
  • Acute alcoholic liver disease
  • Congenital hepatic fibrosis
  • Idiopathic portal hypertension (hepatoportal sclerosis)
  • Schistosomiasis

Posthepatic
  • Budd-Chiari syndrome
  • Constrictive pericarditis
  • Variceal Bleeding
  • Ascites
  • Encephalopathy
  • Hypersplenism



Presentation

File NameTypePermissionsChanged DateDateSize



Anatomy

File NameTypePermissionsChanged DateDateSize

Normal [colspan="2"]

[null]

Portal pressure

3-6 mmHg

Right atrium pressure

2-6 mmHg

Portal Systemic Gradient

1-6 mmHg

Hypertension [colspan="2"]

[null]

Portal pressure

> 10 mmHg

Portal Systemic Gradient

> 6 mmHg

Cirrhosis [colspan="2"]

[null]

Mild - CSP

6 - 10 mmHg

Moderate - CSP

11 - 15 mmHg

Severe - CSP

> 16 mmHg


Indications

  • Acute variceal bleeding that cannot be successfully controlled with medical treatment, including sclerotherapy
  • Recurrent and refractory variceal bleeding or recurrent variceal bleeding in patients who cannot tolerate conventional medical treatment, including sclerotherapy and pharmacologic therapy
  • Refractory ascites
  • Portal decompression in patients with hepatic venous outflow obstruction (Budd-Chiari syndrome), hepatic hydrothorax, or hepatorenal syndrome
  • In case of an pre hepatic hypertension, a mesocaval shunt can be considered



Contra indications

Absolute

  • Right-sided heart failure with increased central venous pressure
  • Polycystic liver disease
  • Severe hepatic failure


Relative

  • Active intrahepatic or systemic infection
  • Severe hepatic encephalopathy poorly controlled with medical therapy
  • Hypervascular hepatic tumors
  • PV thrombosis, with recanalization
  • Bile duct obstruction (high cholangitis risk)
  • MELD score > 18



Workup

  • Child-Pugh Class C
  • MELD > 18
  • INR > 2
  • Total Bilirubin ›3 mg/ di
  • Platelets ‹ 75 K



Pre procedural

  • Consider sedation Midazolam/Fentanyl

Bare metal vs Covered ,
18% less encephalopathy
80% Reduced stent thrombosis



Materials

Essentials

  • Ultrasound
  • Pressure measuring equipment
  • Sterile drapes
  • 1% lidocaine
  • IVUS
  • 8F long sheath
  • Colapinto or the Rösch-Uchida needle set
  • Covered stent (VIATORR)

Non-Essentials



Positioning the patient

  • Supine



The procedure in steps

  • Time out
  • Ultrasound to determine the point of entry
  • Positioning patient
  • Sterile wash and drapes
  • Ultrasound guided access to the jugular vein
  • Deep selective catheterisation of the hepatic vein
  • Pressure measurement
  • The intrahepatic portal vein then is entered with a modified Ross needle.
  • A guide wire is advanced into the main portal vein.
  • A pigtail catheter is positioned in the portal vein, and pressure is again measured ( > 5mmHg is consistent with portal hypertension)
  • The tract between the hepatic and the portal vein is dilated with an angioplasty balloon catheter (8-10mm) followed by stent placement to maintain the communication between both vessels patent
  • Placement of a covered VIATORR stent
  • Postdilatation up to 10 mm
  • In case of gastric varicose, one should proceed and embolus these (high chance of recurrent bleed)



Tips and tricks

  • Advance the sheath in the portal vein, then position the stent



Complications

  • 20-30% Worsened Encephalopathy
  • 10% Hemolysis
  • 1-5% Accelerated Hepatic Failure
  • 5% Infection
  • 5% Cardiac insufficiency
  • 1% Bleeding,
  • 1% Procedural mortality
  • Late stent stenosis

In case of encephalopathy on the basis of increased flow, a hourglass shaped stent can be placed. Inside the TIPS stent



Post-op

  • Bed rest for around 4 h
  • Vitals should be recorded every half hourly for first 2 h post procedure.



Follow-up

Screening Ultrasound 6-12 months interval

TIPS revision may be needed if any of the following is present:

  • Flow-limiting stenosis
  • Occlusion
  • Severe Encephalopathy (TIPS reduction)

Doppler criteria
  • Shunt velocity of <50 cm/s
  • Increase or decrease in shunt velocity of >50cm/s compared with initial post-procedure value
  • Hepatofugal flow in main portal vein



Report



Patient folder

File NameTypePermissionsChanged DateDateSize



Literature

File NameTypePermissionsChanged DateDateSize

  16. Lee EW, Laberge JM. Differential diagnosis of gastrointestinal bleeding. Tech Vasc Interv Radiol 2004; 7: 112-22

  18. Strate LL, Gralnek IM. ACG Clinical Guideline: Management of Patients With Acute Lower Gastrointestinal Bleeding. Am J Gastroenterol. 2016 Apr;111(4):459-74.

  19. Chaudhry V, Hyser MJ, Gracias VH, Gau FC. Colonoscopy: the initial test for acute lower gastrointestinal bleeding. Am Surg. 1998 Aug;64(8):723-8.

  20. Cummings CL. Value of early capsular endoscopy for severe gastrointestinal bleeding. J Natl Med Assoc. 2004;96(12):1653-6.

  21. Appleyard M, Glukhovsky A, Swain P. Wireless-capsule diagnostic endoscopy for recurrent small-bowel bleeding. N Engl J Med. 2001;344(3):232-3.

  24. Lim JK, Ahmed A. Endoscopic approach to the treatment of gastrointestinal bleeding. Tech Vasc Interv Radiol. 2004 Sep;7(3):123-9.

  25. Nicholson AA, Ettles DF, Hartley JE, et al. Transcatheter coil embolotherapy: a safe and effective option for major colonic haemorrhage. Gut 1998; 43:79–84.

  26. Zuckier LS. Acute gastrointestinal bleeding. Semin Nucl Med. 2003 Oct;33(4):297-311.

  27. Imbembo AL, Diverticular disease of the colon. In: Sabiston D, Editor. Textbook of Surgery (14th edn). Philadelphia, PA:WB Saunders, 1992:910.

  29. Loffroy R, Rao P, Ota S, De Lin M, Kwak BK, Geschwind JF. Embolization of acute nonvariceal upper gastrointestinal hemorrhage resistant to endoscopic treatment: results and predictors of recurrent bleeding. Cardiovasc Intervent Radiol. 2010 Dec;33(6):1088-100. doi: 10.1007/s00270-010-9829-7. Epub 2010 Mar 16.

  31. Eriksson LG, Sundbom M, Gustavsson S, Nyman R. Endoscopic marking with a metallic clip facilitates transcatheter arterial embolization in upper peptic ulcer bleeding. J Vasc Interv Radiol. 2006 Jun;17(6):959-64.

  32. Anthony S, Milburn S, Uberoi R. Multi-detector CT: review of its use in acute GI haemorrhage. Clin Radiol. 2007 Oct;62(10):938-49.

  33. Ernst O, Bulois P, Saint-Drenant S, Leroy C, Paris JC, Sergent G. Helical CT in acute lower gastrointestinal bleeding. Eur Radiol. 2003;13(1):114-7

  34. Mirsadraee S, Tirukonda P, Nicholson A, Everett SM, McPherson SJ. Embolization for non-variceal upper gastrointestinal tract haemorrhage: a systematic review. Clin Radiol 2011;66:500-509.

  35. Loffroy R, Guiu B, D'Athis P, Mezzetta L, Gagnaire A, Jouve JL, Ortega-Deballon P, Cheynel N, Cercueil JP, Krausé D. Arterial embolotherapy for endoscopically unmanageable acute gastroduodenal hemorrhage: predictors of early rebleeding. Clin Gastroenterol Hepatol. 2009 May;7(5):515-23.

  36. Aina R, Oliva VL, Therasse E, et al. Arterial embolotherapy for upper gastrointestinal hemorrhage: outcome assessment. J Vasc Interv Radiol 2001;12:195-200.

  37. Mirsadraee S, Tirukonda P, Nicholson A, Everett SM, McPherson SJ. Embolization for non-variceal upper gastrointestinal tract haemorrhage: a systematic review. Clin Radiol 2011;66:500-509.

  38. Loffroy R, Guiu B, Cercueil JP, Lepage C, Latournerie M, Hillon P, Rat P, Ricolfi F, Krausé D. Refractory bleeding from gastroduodenal ulcers: arterial embolization in high-operative-risk patients. J Clin Gastroenterol. 2008 Apr;42(4):361-7.

  39. Loffroy R, Guiu B, D'Athis P, Mezzetta L, Gagnaire A, Jouve JL, Ortega-Deballon P, Cheynel N, Cercueil JP, Krausé D. Arterial embolotherapy for endoscopically unmanageable acute gastroduodenal hemorrhage: predictors of early rebleeding. Clin Gastroenterol Hepatol. 2009 May;7(5):515-23.

  40. Poultsides GA, Kim CJ, Orlando R 3rd, Peros G, Hallisey MJ, Vignati PV. Angiographic embolization for gastroduodenal hemorrhage: safety, efficacy, and predictors of outcome. Arch Surg 2008;143:457-461.

  42. Gordon RL, Ahl KL, Kerlan RK, Wilson MW, LaBerge JM, Sandhu JS, Ring EJ, Welton ML. Selective arterial embolization for the control of lower gastrointestinal bleeding. Am J Surg. 1997;174(1):24-8.

  43. Funaki B, Kostelic JK, Lorenz J, Ha TV, Yip DL, Rosenblum JD, et al. Superselective microcoil embolization of colonic hemorrhage. AJR Am J Roentgenol 2001;177:829-836 7.

  44. Bandi R, Shetty PC, Sharma RP, Burke TH, Burke MW, Kastan D. Superselective arterial embolization for the treatment of lower gastrointestinal hemorrhage. J Vasc Interv Radiol 2001;12:1399-1405.

  45. Maleux G, Roeflaer F, Heye S, Vandersmissen J, Vliegen AS, Demedts I, et al. Long-term outcome of transcatheter embolotherapy for acute lower gastrointestinal hemorrhage. Am J Gastroenterol 2009;104:2042-2046

  46. Leitman IM, Paull DE, Shires GT 3rd. Evaluation and management of massive lower gastrointestinal hemorrhage. Ann Surg 1989;209:175-180

  47. Rosenkrantz H, Bookstein JJ, Rosen RJ, Goff WB 2nd, Healy JF. Postembolic colonic infarction. Radiology 1982;142:47-51.

  48. Koh DC, Luchtefeld MA, Kim DG, Knox MF, Fedeson BC, Vanerp JS, et al. Efficacy of transarterial embolization as definitive treatment in lower gastrointestinal bleeding. Colorectal Dis 2009;11:53-59

  49. Lipof T, Sardella WV, Bartus CM, Johnson KH, Vignati PV, Cohen JL. The efficacy and durability of super-selective embolization in the treatment of lower gastrointestinal bleeding. Dis Colon Rectum 2008;51:301-305

  1. Lee EW, Laberge JM. Differential diagnosis of gastrointestinal bleeding. Tech Vasc Interv Radiol 2004; 7: 112-22

  2. Baum ST. Arteriographic diagnosis and treatment of gastrointestinal bleeding. In Baum ST, Pentecost MJ, eds. Abrams' angiography interventional radiology. 2nd ed. Philadelphia, Pa:Lippincott, Williams & Wilkins, 2006:488.

  4. Poultsides GA, Kim CJ, Orlando R 3rd, et al. Angiographic embolization for gastroduodenal hemorrhage: safety, efficacy, and predictors of outcome. Arch Surg. 2008;143:457-461.

  5. Eriksson LG, Sundbom M, Gustavsson S, Nyman R. Endoscopic marking with a metallic clip facilitates transcatheter arterial embolization in upper peptic ulcer bleeding. J Vasc Interv Radiol. 2006;17:959-964.

  6. Dixon S, Chan V, Shrivastava V et al. Is there a role for empiric gastroduodenal artery embolization in the management of patients with active upper GI hemorrhage? Cardiovasc Intervent Radiol. 2013 Aug;36(4):970-7.

  7. Shin JH. Recent update of embolization of upper gastrointestinal tract bleeding. Korean J Radiol 2012;13 Suppl 1:S31-S39.

  9. van Leerdam ME. Epidemiology of acute upper gastrointestinal bleeding. Best Pract Res Clin Gastroenterol. 2008;22(2):209-24.

  10. Sildiroglu O, Muasher J, Arslan B, Sabri SS, Saad WE, Angle JF, Matsumoto AH, Turba UC. Outcomes of patients with acute upper gastrointestinal nonvariceal hemorrhage referred to interventional radiology for potential embolotherapy. J Clin Gastroenterol. 2014;48(8):687-92.

  11. Strate LL, Gralnek IM. ACG Clinical Guideline: Management of Patients With Acute Lower Gastrointestinal Bleeding. Am J Gastroenterol. 2016 Apr;111(4):459-74.

  13. van Dam J, Brugge WR. Endoscopy of the upper gastrointestinal tract. N Engl J Med. 1999;341(23):1738-48.

  15. Lefkovitz Z, Cappell MS, Lookstein R, Mitty HA, Gerard PS. Radiologic diagnosis and treatment of gastrointestinal hemorrhage and ischemia. Med Clin North Am. 2002 Nov;86(6):1357-99.

  16. Lee EW, Laberge JM. Differential diagnosis of gastrointestinal bleeding. Tech Vasc Interv Radiol 2004; 7: 112-22

  18. Strate LL, Gralnek IM. ACG Clinical Guideline: Management of Patients With Acute Lower Gastrointestinal Bleeding. Am J Gastroenterol. 2016 Apr;111(4):459-74.

  19. Chaudhry V, Hyser MJ, Gracias VH, Gau FC. Colonoscopy: the initial test for acute lower gastrointestinal bleeding. Am Surg. 1998 Aug;64(8):723-8.

  20. Cummings CL. Value of early capsular endoscopy for severe gastrointestinal bleeding. J Natl Med Assoc. 2004;96(12):1653-6.

  21. Appleyard M, Glukhovsky A, Swain P. Wireless-capsule diagnostic endoscopy for recurrent small-bowel bleeding. N Engl J Med. 2001;344(3):232-3.

  24. Lim JK, Ahmed A. Endoscopic approach to the treatment of gastrointestinal bleeding. Tech Vasc Interv Radiol. 2004 Sep;7(3):123-9.

  25. Nicholson AA, Ettles DF, Hartley JE, et al. Transcatheter coil embolotherapy: a safe and effective option for major colonic haemorrhage. Gut 1998; 43:79–84.

  26. Zuckier LS. Acute gastrointestinal bleeding. Semin Nucl Med. 2003 Oct;33(4):297-311.

  27. Imbembo AL, Diverticular disease of the colon. In: Sabiston D, Editor. Textbook of Surgery (14th edn). Philadelphia, PA:WB Saunders, 1992:910.

  29. Loffroy R, Rao P, Ota S, De Lin M, Kwak BK, Geschwind JF. Embolization of acute nonvariceal upper gastrointestinal hemorrhage resistant to endoscopic treatment: results and predictors of recurrent bleeding. Cardiovasc Intervent Radiol. 2010 Dec;33(6):1088-100. doi: 10.1007/s00270-010-9829-7. Epub 2010 Mar 16.

  31. Eriksson LG, Sundbom M, Gustavsson S, Nyman R. Endoscopic marking with a metallic clip facilitates transcatheter arterial embolization in upper peptic ulcer bleeding. J Vasc Interv Radiol. 2006 Jun;17(6):959-64.

  32. Anthony S, Milburn S, Uberoi R. Multi-detector CT: review of its use in acute GI haemorrhage. Clin Radiol. 2007 Oct;62(10):938-49.

  33. Ernst O, Bulois P, Saint-Drenant S, Leroy C, Paris JC, Sergent G. Helical CT in acute lower gastrointestinal bleeding. Eur Radiol. 2003;13(1):114-7

  34. Mirsadraee S, Tirukonda P, Nicholson A, Everett SM, McPherson SJ. Embolization for non-variceal upper gastrointestinal tract haemorrhage: a systematic review. Clin Radiol 2011;66:500-509.

  35. Loffroy R, Guiu B, D'Athis P, Mezzetta L, Gagnaire A, Jouve JL, Ortega-Deballon P, Cheynel N, Cercueil JP, Krausé D. Arterial embolotherapy for endoscopically unmanageable acute gastroduodenal hemorrhage: predictors of early rebleeding. Clin Gastroenterol Hepatol. 2009 May;7(5):515-23.

  36. Aina R, Oliva VL, Therasse E, et al. Arterial embolotherapy for upper gastrointestinal hemorrhage: outcome assessment. J Vasc Interv Radiol 2001;12:195-200.

  37. Mirsadraee S, Tirukonda P, Nicholson A, Everett SM, McPherson SJ. Embolization for non-variceal upper gastrointestinal tract haemorrhage: a systematic review. Clin Radiol 2011;66:500-509.

  38. Loffroy R, Guiu B, Cercueil JP, Lepage C, Latournerie M, Hillon P, Rat P, Ricolfi F, Krausé D. Refractory bleeding from gastroduodenal ulcers: arterial embolization in high-operative-risk patients. J Clin Gastroenterol. 2008 Apr;42(4):361-7.

  39. Loffroy R, Guiu B, D'Athis P, Mezzetta L, Gagnaire A, Jouve JL, Ortega-Deballon P, Cheynel N, Cercueil JP, Krausé D. Arterial embolotherapy for endoscopically unmanageable acute gastroduodenal hemorrhage: predictors of early rebleeding. Clin Gastroenterol Hepatol. 2009 May;7(5):515-23.

  40. Poultsides GA, Kim CJ, Orlando R 3rd, Peros G, Hallisey MJ, Vignati PV. Angiographic embolization for gastroduodenal hemorrhage: safety, efficacy, and predictors of outcome. Arch Surg 2008;143:457-461.

  42. Gordon RL, Ahl KL, Kerlan RK, Wilson MW, LaBerge JM, Sandhu JS, Ring EJ, Welton ML. Selective arterial embolization for the control of lower gastrointestinal bleeding. Am J Surg. 1997;174(1):24-8.

  43. Funaki B, Kostelic JK, Lorenz J, Ha TV, Yip DL, Rosenblum JD, et al. Superselective microcoil embolization of colonic hemorrhage. AJR Am J Roentgenol 2001;177:829-836 7.

  44. Bandi R, Shetty PC, Sharma RP, Burke TH, Burke MW, Kastan D. Superselective arterial embolization for the treatment of lower gastrointestinal hemorrhage. J Vasc Interv Radiol 2001;12:1399-1405.

  45. Maleux G, Roeflaer F, Heye S, Vandersmissen J, Vliegen AS, Demedts I, et al. Long-term outcome of transcatheter embolotherapy for acute lower gastrointestinal hemorrhage. Am J Gastroenterol 2009;104:2042-2046

  46. Leitman IM, Paull DE, Shires GT 3rd. Evaluation and management of massive lower gastrointestinal hemorrhage. Ann Surg 1989;209:175-180

  47. Rosenkrantz H, Bookstein JJ, Rosen RJ, Goff WB 2nd, Healy JF. Postembolic colonic infarction. Radiology 1982;142:47-51.

  48. Koh DC, Luchtefeld MA, Kim DG, Knox MF, Fedeson BC, Vanerp JS, et al. Efficacy of transarterial embolization as definitive treatment in lower gastrointestinal bleeding. Colorectal Dis 2009;11:53-59

  49. Lipof T, Sardella WV, Bartus CM, Johnson KH, Vignati PV, Cohen JL. The efficacy and durability of super-selective embolization in the treatment of lower gastrointestinal bleeding. Dis Colon Rectum 2008;51:301-305
