ARTERIAL EMBOLIZATION

BRONCHIAL ARTERY EMBOLIZATION

Introduction

Last updated: apr 5, 2023

Massive hemoptysis is a frightening and potentially life-threatening clinical event. Patients with chronic inflammatory lung diseases such as bronchiectasis, sarcoidosis, tuberculosis, and cystic fibrosis develop markedly hypertrophied and fragile bronchial arteries that may lead to clinically significant hemoptysis.

My Image


Anatomy

File NameTypePermissionsChanged DateDateSize
pdf
 Variations of bronchial artery origin pdf 0644 2025070109252601-Jul-2025 09:25 2023031711052217-Mar-2023 11:05 762 KB Preview Print Download

My Image


Indications

  • Massive hemoptysis (defined as bleeding greater than 240 to 300 mL/24 hours) carries a 50 to 85% mortality rate when treated conservatively. Death is most often due to asphyxiation from the aspiration of blood, leading to airway obstruction.
  • Recurrent bouts of moderate hemorrhage (three or more bouts of 100 ml of blood per day within a week) are now also considered a major hemorrhagic event.
  • In addition, chronic or slowly increasing hemoptysis is considered an indication for transcatheter therapy.



Contra indications

Absolute

  • The only absolute contraindication is a supplying branch to the heart, brain or spinal cord.
  • And of course are the usual contraindications, absolute or relative, for angiography in general

Relative



Workup

  • Bronchoscopy (BC)
    • lateralisation
    • clot extraction
    • direct instillation of medications
    • tamponade
    • ablation of haemorrhagic arteries
    • supports selective intubation
    • The source is most likely to be located during active haemoptysis (in 73–93% of cases) or within 24–48 h of cessation



Pre procedural

  • Stop any anti-coagulation medication
  • Correct any coagulopathy before embolization, (achieving hemostasis depends on ability to clot).
  • Computed tomography angiography (CTA)



Materials

Essentials

Diagnostic Catheters

  • reversed curved shapes
  • forward-looking shapes
Microcatheter
  • 2.7–2.9 Fr. preferred
Microwires
  • 0.014 00or 0.016 00in diameter, hydrophilic coating preferred
Non-ionic contrast
Embolic agents
  • spherical or non-spherical particles (300–900 lm)
  • non-spherical, PVA particles, 355–500 micronrecommended for BAE.
  • never use particles with a diameter <300 lm for BAE
  • liquid embolic (NBCA, non-adhesive, high-viscous polymers)
  • gelfoam (only as supplementary agent)
  • microcoils (in specific situations)

Non-Essentials



Positioning the patient

  • Supine



Tips and tricks

  • Where clinical or imaging lateralisation of the bleeding site is uncertain, treat any enlarged bronchial arteries at the first session.
  • Carefully scrutinize angiography for any signs of non-target vessels leading to brain, spine cord and heart before starting the embolisation procedure
  • At all times embolisation is performed with a small (1 ml) Luer-lock syringe under active fluoroscopy to ensure any sign of reflux is picked up as early as possible.
  • Use the left main bronchus as a reliable reference point for catheterisation of the right or left bronchial arteries
  • In case of bronchial-to-pulmonary shunts, use larger particles and coils
  • Actively search and embolise as many non-bronchial systemic collaterals in the first BAE procedure as possible to decrease recurrence rates of haemoptysis. Angiography of the subclavian arteries should be considered, to determine the origin of ectopic BA supplied by internal thoracic arteries or thyrocervical trunks, in apical- predominant disease



Complications

  • Chest pain and dysphagia common within the first week (>30%)
  • Post-embolization syndrome (2-30%)
  • Spinal cord ischemia (<1%)
  • Bronchial artery dissection or perforation (3-10%)
  • Transverse myelitis (based on non-ionic contrast)
  • Rare reported major complications include bronchial infarction, oesophago-bronchial fistula, myocardial infarction, ischemic colitis, transient cortical blindness, phrenic nerve injury, and stroke all of which can be attributed to non-target embolisation.
  • Death



Post-op

  • Observe for signs of neurological deficit.
  • Provide supplemental oxygen, IV fluids, and blood pressure maintenance (mean arterial pressure above 80 mmHg) if spinal cord damage occurs.
  • A spinal drain should be inserted if spinal cord infarction cannot be immediately confirmed



Report

Time out akkoord. Patient in rugligging. Wassen met chloorhexidine en steriel afdekken. Echografisch geen stenose in de AFCD. Retrograde toegang, met 6F sheath. 5000 IE Heparine.

Superselectieve katheteisatie van de ... bronchiaal arterie, afgaande van ... Angiografie toont geen voorziening van de spinalis anterior. Embolisatie met ... micron partikels.

Angioseal



Literature

File NameTypePermissionsChanged DateDateSize

  1. J. Mark Ryan, MD, S. M. Key, Siobhan A. Dumbleton, MD, and Tony P. Smith, MD Nonlocalized Lower Gastrointestinal Bleeding: Provocative Bleeding Studies with Intraarterial tPA, Heparin, and Tolazoline J Vasc Interv Radiol 2001 Nov;12(11):1273-7

  2. Baum ST. Arteriographic diagnosis and treatment of gastrointestinal bleeding. In Baum ST, Pentecost MJ, eds. Abrams' angiography interventional radiology. 2nd ed. Philadelphia, Pa:Lippincott, Williams & Wilkins, 2006:488.

  4. Poultsides GA, Kim CJ, Orlando R 3rd, et al. Angiographic embolization for gastroduodenal hemorrhage: safety, efficacy, and predictors of outcome. Arch Surg. 2008;143:457-461.

  5. Eriksson LG, Sundbom M, Gustavsson S, Nyman R. Endoscopic marking with a metallic clip facilitates transcatheter arterial embolization in upper peptic ulcer bleeding. J Vasc Interv Radiol. 2006;17:959-964.

  6. Dixon S, Chan V, Shrivastava V et al. Is there a role for empiric gastroduodenal artery embolization in the management of patients with active upper GI hemorrhage? Cardiovasc Intervent Radiol. 2013 Aug;36(4):970-7.

  7. Shin JH. Recent update of embolization of upper gastrointestinal tract bleeding. Korean J Radiol 2012;13 Suppl 1:S31-S39.

  9. van Leerdam ME. Epidemiology of acute upper gastrointestinal bleeding. Best Pract Res Clin Gastroenterol. 2008;22(2):209-24.

  10. Sildiroglu O, Muasher J, Arslan B, Sabri SS, Saad WE, Angle JF, Matsumoto AH, Turba UC. Outcomes of patients with acute upper gastrointestinal nonvariceal hemorrhage referred to interventional radiology for potential embolotherapy. J Clin Gastroenterol. 2014;48(8):687-92.

  11. Strate LL, Gralnek IM. ACG Clinical Guideline: Management of Patients With Acute Lower Gastrointestinal Bleeding. Am J Gastroenterol. 2016 Apr;111(4):459-74.

  13. van Dam J, Brugge WR. Endoscopy of the upper gastrointestinal tract. N Engl J Med. 1999;341(23):1738-48.

  15. Lefkovitz Z, Cappell MS, Lookstein R, Mitty HA, Gerard PS. Radiologic diagnosis and treatment of gastrointestinal hemorrhage and ischemia. Med Clin North Am. 2002 Nov;86(6):1357-99.

  16. Lee EW, Laberge JM. Differential diagnosis of gastrointestinal bleeding. Tech Vasc Interv Radiol 2004; 7: 112-22

  18. Strate LL, Gralnek IM. ACG Clinical Guideline: Management of Patients With Acute Lower Gastrointestinal Bleeding. Am J Gastroenterol. 2016 Apr;111(4):459-74.

  19. Chaudhry V, Hyser MJ, Gracias VH, Gau FC. Colonoscopy: the initial test for acute lower gastrointestinal bleeding. Am Surg. 1998 Aug;64(8):723-8.

  20. Cummings CL. Value of early capsular endoscopy for severe gastrointestinal bleeding. J Natl Med Assoc. 2004;96(12):1653-6.

  21. Appleyard M, Glukhovsky A, Swain P. Wireless-capsule diagnostic endoscopy for recurrent small-bowel bleeding. N Engl J Med. 2001;344(3):232-3.

  24. Lim JK, Ahmed A. Endoscopic approach to the treatment of gastrointestinal bleeding. Tech Vasc Interv Radiol. 2004 Sep;7(3):123-9.

  25. Nicholson AA, Ettles DF, Hartley JE, et al. Transcatheter coil embolotherapy: a safe and effective option for major colonic haemorrhage. Gut 1998; 43:79–84.

  26. Zuckier LS. Acute gastrointestinal bleeding. Semin Nucl Med. 2003 Oct;33(4):297-311.

  27. Imbembo AL, Diverticular disease of the colon. In: Sabiston D, Editor. Textbook of Surgery (14th edn). Philadelphia, PA:WB Saunders, 1992:910.

  29. Loffroy R, Rao P, Ota S, De Lin M, Kwak BK, Geschwind JF. Embolization of acute nonvariceal upper gastrointestinal hemorrhage resistant to endoscopic treatment: results and predictors of recurrent bleeding. Cardiovasc Intervent Radiol. 2010 Dec;33(6):1088-100. doi: 10.1007/s00270-010-9829-7. Epub 2010 Mar 16.

  31. Eriksson LG, Sundbom M, Gustavsson S, Nyman R. Endoscopic marking with a metallic clip facilitates transcatheter arterial embolization in upper peptic ulcer bleeding. J Vasc Interv Radiol. 2006 Jun;17(6):959-64.

  32. Anthony S, Milburn S, Uberoi R. Multi-detector CT: review of its use in acute GI haemorrhage. Clin Radiol. 2007 Oct;62(10):938-49.

  33. Ernst O, Bulois P, Saint-Drenant S, Leroy C, Paris JC, Sergent G. Helical CT in acute lower gastrointestinal bleeding. Eur Radiol. 2003;13(1):114-7

  34. Mirsadraee S, Tirukonda P, Nicholson A, Everett SM, McPherson SJ. Embolization for non-variceal upper gastrointestinal tract haemorrhage: a systematic review. Clin Radiol 2011;66:500-509.

  35. Loffroy R, Guiu B, D'Athis P, Mezzetta L, Gagnaire A, Jouve JL, Ortega-Deballon P, Cheynel N, Cercueil JP, Krausé D. Arterial embolotherapy for endoscopically unmanageable acute gastroduodenal hemorrhage: predictors of early rebleeding. Clin Gastroenterol Hepatol. 2009 May;7(5):515-23.

  36. Aina R, Oliva VL, Therasse E, et al. Arterial embolotherapy for upper gastrointestinal hemorrhage: outcome assessment. J Vasc Interv Radiol 2001;12:195-200.

  37. Mirsadraee S, Tirukonda P, Nicholson A, Everett SM, McPherson SJ. Embolization for non-variceal upper gastrointestinal tract haemorrhage: a systematic review. Clin Radiol 2011;66:500-509.

  38. Loffroy R, Guiu B, Cercueil JP, Lepage C, Latournerie M, Hillon P, Rat P, Ricolfi F, Krausé D. Refractory bleeding from gastroduodenal ulcers: arterial embolization in high-operative-risk patients. J Clin Gastroenterol. 2008 Apr;42(4):361-7.

  39. Loffroy R, Guiu B, D'Athis P, Mezzetta L, Gagnaire A, Jouve JL, Ortega-Deballon P, Cheynel N, Cercueil JP, Krausé D. Arterial embolotherapy for endoscopically unmanageable acute gastroduodenal hemorrhage: predictors of early rebleeding. Clin Gastroenterol Hepatol. 2009 May;7(5):515-23.

  40. Poultsides GA, Kim CJ, Orlando R 3rd, Peros G, Hallisey MJ, Vignati PV. Angiographic embolization for gastroduodenal hemorrhage: safety, efficacy, and predictors of outcome. Arch Surg 2008;143:457-461.

  42. Gordon RL, Ahl KL, Kerlan RK, Wilson MW, LaBerge JM, Sandhu JS, Ring EJ, Welton ML. Selective arterial embolization for the control of lower gastrointestinal bleeding. Am J Surg. 1997;174(1):24-8.

  43. Funaki B, Kostelic JK, Lorenz J, Ha TV, Yip DL, Rosenblum JD, et al. Superselective microcoil embolization of colonic hemorrhage. AJR Am J Roentgenol 2001;177:829-836 7.

  44. Bandi R, Shetty PC, Sharma RP, Burke TH, Burke MW, Kastan D. Superselective arterial embolization for the treatment of lower gastrointestinal hemorrhage. J Vasc Interv Radiol 2001;12:1399-1405.

  45. Maleux G, Roeflaer F, Heye S, Vandersmissen J, Vliegen AS, Demedts I, et al. Long-term outcome of transcatheter embolotherapy for acute lower gastrointestinal hemorrhage. Am J Gastroenterol 2009;104:2042-2046

  46. Leitman IM, Paull DE, Shires GT 3rd. Evaluation and management of massive lower gastrointestinal hemorrhage. Ann Surg 1989;209:175-180

  47. Rosenkrantz H, Bookstein JJ, Rosen RJ, Goff WB 2nd, Healy JF. Postembolic colonic infarction. Radiology 1982;142:47-51.

  48. Koh DC, Luchtefeld MA, Kim DG, Knox MF, Fedeson BC, Vanerp JS, et al. Efficacy of transarterial embolization as definitive treatment in lower gastrointestinal bleeding. Colorectal Dis 2009;11:53-59

  49. Lipof T, Sardella WV, Bartus CM, Johnson KH, Vignati PV, Cohen JL. The efficacy and durability of super-selective embolization in the treatment of lower gastrointestinal bleeding. Dis Colon Rectum 2008;51:301-305
